System 3R 90476.02, Manual chuck adapter, Macro-Macro

Distance adapter to extend the mache spindle. Mechanical clamping from the side. Solid X & Y-references Extension length 250 mm Ready for auto...
SKU: 90476.02Categories: Sinker EDM Tooling, System 3R Chucks, System 3R Tooling Tags: 90476.02,Macro-Macro,Sinker EDM,
Description

Distance adapter to extend the mache spindle. Mechanical clamping from the side.

  • Solid X & Y-references
  • Extension length 250 mm
  • Ready for automation
  • Flushing duct
  • Recommended clamping torque 6 Nm
  • Permissable torque: 135 Nm
  • Suitable drawbar 3R-605.2 or similar.
  • Weight 9 kg.
