System 3R C260320, Chuck HSP built-up with flange with mounting bores

For installation on a machine table.Please submit dimension diagram of the mounting bores. Clamping force: 15.000 N Holding force: 60.000 N Materi...
SKU: C260320Categories: System 3R Chucks, System 3R Tooling Tags: C260320,Chuck HSP built-up with flange with mounting bores,Sinker EDM,
Description

For installation on a machine table.

Please submit dimension diagram of the mounting bores.

  • Clamping force: 15.000 N
  • Holding force: 60.000 N
  • Material chuck: stainless steel, hardened and ground
  • Material flange: stainless steel, heat pre-treated
  • Hydraulic pressure: 30 - 70 bar
  • Accuracy: < 0.005 mm
  • Dimensions: Ø 178 x 52 mm
  • Spare part set: S840000
