System 3R Clamping force meter kit, Macro

System 3R Clamping force meter kit, Macro (3R-SSP115-BASE)

For both pneumatic and manual chucks. This stand alone unit in combination with individual drawbars or drawbar kits, able to cover MacroJunior, Macro, MacroMagnum and Dynafix.

Note: Require drawbars with bayonet interface similar to 3R-605.1.

• Add-on kit for use in Macro/MacroMagnum, 3R-SSP115-MACRO
• Operating temp. +10 to +40° C
• Gauge size Ø90x47 mm
• Working range 1-22 kN
• Deviation ± 0.1 kN.
• Weight:
• Display 0.34 kg.
• Gauge 1.3 kg.
